MayaFlux: Multi-Domain Real-Time Scheduling with C++20

Ranjith Hegde · github.com/MayaFlux/MayaFlux · mayaflux.org

C++Online 2026 · Poster

Architectural Constraints of Heterogeneous Real-Time Systems

Real-time multimedia systems do not run in a single loop. They run several incompatible ones at once: audio callbacks at 48kHz (~20μs per sample) with hard real-time deadlines, graphics render loops at 60–144 FPS (~7–16ms per frame) with soft frame pacing, asynchronous input from MIDI/HID/OSC devices with backend-defined threading, and user-defined coroutines that may demand either sample accuracy or frame-rate granularity depending on intent. These contexts cannot be collapsed into a single abstraction without erasing the constraints that make them correct.

Historically, creative computing frameworks addressed this by separation. Pure Data distinguishes control rate from audio rate. Max/MSP sandboxes gen~ from its message scheduler. openFrameworks treats audio as an addon to an OpenGL draw loop. SuperCollider splits synthesis and language into separate processes. These were sound engineering decisions for their time: isolate domains to preserve guarantees.

But isolation introduces friction. Data fragments at boundaries. Scheduling becomes glue code. Coordination requires mutexes, queues, or ad-hoc bridges. Some loops cannot legally block; others can. Some require deterministic timing; others tolerate jitter. When independent execution contexts must cooperate without violating each other’s safety constraints, the architectural problem becomes deeper than “how to schedule.”

The question is not how to unify everything under one scheduler. The question is how independent real-time execution contexts can coexist without collapsing into a single abstraction.

This implies several simultaneous requirements:

Independent execution loops (audio, graphics, input backends, user code) operating concurrently.
Lock-free coordination, because some contexts cannot block or yield.
Temporal intent that survives movement across threads and rate domains.
Compile-time data unification, so computation does not fragment into domain-specific representations at every boundary.

Without lock-free mutation patterns, independent loops collide. Without coroutines, cross-domain temporal coordination becomes brittle or centralized. Without type-level data abstraction, every boundary degenerates into copying, conversion, and special-case glue.

When these constraints are treated as fundamental rather than incidental, a different class of system emerges: a single computation can exist simultaneously at audio-rate precision, graphics-rate updates, input-driven events, and user-defined timing, without rewriting it per domain and without compromising real-time correctness.

This is not an isolated problem to any single domain programming. Game engines coordinate rendering, physics, and input at mismatched rates. Robotics systems coordinate sensors, actuators, and planners. Any real-time C++ system with heterogeneous execution models faces the same architectural tension.

The problem is coexistence without collapse.

A Lock-Free, Coroutine-Centric Coordination Architecture

MayaFlux approaches this problem by designing for coexistence from the outset.

It is an open-source C++20/23 framework (GPL-3.0) built around the idea that independent execution contexts should remain independent. Audio callbacks, graphics threads, input backends, and user-defined coroutines operate within a single process, but they do not share a forced abstraction or centralized scheduler. Each domain retains its own clock, threading model, and evaluation semantics.

The coordination model is architectural, not incidental.

Lock-free mutation patterns allow graph structures to evolve without blocking real-time threads. C++20 coroutines provide a weaving layer through which temporal intent can move across threads and rate domains without inventing a global scheduler. Compile-time data unification treats audio, visual, and control signals as structured numerical data rather than domain-specific types, allowing computation to exist identically across contexts.

The question MayaFlux explores is not how to merge domains, but what coordination patterns become possible when coexistence is treated as a first principle, and when modern C++ facilities make that coexistence structurally expressible.

The result is a system in which heterogeneous real-time loops can coordinate without collapsing into a single timing model, without fragmenting into glue code, and without sacrificing the guarantees that make each domain correct.

MayaFlux Architecture

1 · Lock-Free Coordination Across Thread Boundaries

Click to expand

Real-time threads cannot block. But processing graphs must evolve: nodes added, buffers removed, processors swapped; often while audio callbacks are mid-flight at 48 kHz. MayaFlux solves this with a CAS-based pending operation pattern: any thread can mutate the graph at any time, real-time threads never block, and pending changes drain at cycle boundaries. The same pattern drives nodes, buffers, and processors identically.

The Pattern: CAS-Based Pending Operations

The central challenge: nodes, buffers, and processors must be added and removed dynamically while real-time threads are actively processing. MayaFlux solves this with a fixed-size pending operation array scanned via compare_exchange_strong:

// RootNode::register_node — called from any thread
void RootNode::register_node(const std::shared_ptr<Node>& node)
{
    if (m_is_processing.load(std::memory_order_acquire)) {

        // Try to claim a pending slot via CAS
        for (auto& m_pending_op : m_pending_ops) {
            bool expected = false;
            if (m_pending_op.active.compare_exchange_strong(
                    expected, true,
                    std::memory_order_acquire,
                    std::memory_order_relaxed)) {
                m_pending_op.node = node;
                atomic_add_flag(node->m_state, NodeState::INACTIVE);
                m_pending_count.fetch_add(1, std::memory_order_relaxed);
                return;
            }
        }

        // All slots full — wait for processing to finish
        while (m_is_processing.load(std::memory_order_acquire)) {
            m_is_processing.wait(true, std::memory_order_acquire);
        }
    }

    m_Nodes.push_back(node);
    atomic_add_flag(node->m_state, NodeState::ACTIVE);
}

This pattern appears identically in RootBuffer::add_child_buffer and BufferProcessingChain::queue_pending_processor_op — the same CAS-claim → deferred-apply structure is used for nodes, buffers, and processors. No mutexes anywhere in the processing path.

Atomic State Flags

Node state is managed through atomic bitfield operations using CAS loops. Multiple state transitions (ACTIVE, INACTIVE, PROCESSED, PENDING_REMOVAL) coexist without locking:

void atomic_add_flag(std::atomic<NodeState>& state, NodeState flag)
{
    auto current = state.load();
    NodeState desired;
    do {
        desired = static_cast<NodeState>(current | flag);
    } while (!state.compare_exchange_weak(current, desired,
        std::memory_order_acq_rel,
        std::memory_order_acquire));
}

Multi-Buffer Snapshot Coordination

When multiple buffers reference the same node, only one should trigger save_state per processing cycle. This is handled by atomic context claiming:

bool Node::try_claim_snapshot_context(uint64_t context_id)
{
    uint64_t expected = 0;
    return m_snapshot_context_id.compare_exchange_strong(
        expected, context_id,
        std::memory_order_acq_rel,
        std::memory_order_acquire);
}

The first buffer to claim the context saves/restores state; subsequent buffers detect the active snapshot and use the already-computed output. Zero contention.

Processing Cycle Fence

The processing cycle itself is guarded by a single atomic bool with wait/notify_all (C++20):

bool RootNode::preprocess()
{
    bool expected = false;
    if (!m_is_processing.compare_exchange_strong(expected, true,
            std::memory_order_acquire, std::memory_order_relaxed)) {
        return false;
    }

    if (m_pending_count.load(std::memory_order_relaxed) > 0) {
        process_pending_operations();
    }
    return true;
}

void RootNode::postprocess()
{
    for (auto& node : m_Nodes) {
        node->request_reset_from_channel(m_channel);
    }
    m_is_processing.store(false, std::memory_order_release);
    m_is_processing.notify_all();
}

The entire node graph processes inside a preprocess → compute → postprocess window. Pending operations are drained at the boundary. External threads that attempt registration during processing either claim a pending slot (fast path) or wait on the atomic (slow path, rare).

2 · C++20 Coroutines Weaving Temporal Intent

Click to expand

Traditional real-time systems fragment temporal logic across callbacks, timers, and state machines. Coroutines invert this: a single function body describes a complete temporal narrative: gates, triggers, delays, patterns, as sequential code. The scheduler determines when to resume; the coroutine describes what and how long. Timing is deterministic and jitter-free: one co_await SampleDelay{48000} is exactly one second at 48 kHz, every time.

The Architecture: Vruta (Infrastructure) + Kriya (Patterns)

MayaFlux splits coroutine concerns into two namespaces. Vruta provides the scheduling infrastructure — TaskScheduler, SoundRoutine (the coroutine type), domain clocks. Kriya provides the creative temporal patterns — awaiters that encode timing intent.

Sample-Accurate Delay

The fundamental awaiter is Kriya::SampleDelay. It advances the coroutine’s resumption point by an exact number of discrete time units:

struct SampleDelay {
    using promise_handle = Vruta::audio_promise;
    uint64_t samples_to_wait;

    [[nodiscard]] bool await_ready() const { return samples_to_wait == 0; }
    void await_resume() { }

    void await_suspend(std::coroutine_handle<Vruta::promise_type> h)
    {
        auto& promise = h.promise();
        promise.next_sample += samples_to_wait;
    }
};

Because next_sample is updated inside the coroutine frame and the TaskScheduler compares it against the current clock position, timing is deterministic: it does not depend on wall-clock jitter, thread scheduling, or processing load. One co_await SampleDelay{48000} is exactly one second at 48 kHz, every time.

Clock Domains and Token-Based Routing

TaskScheduler maintains separate clocks for each ProcessingToken:

scheduler->process_token(Vruta::ProcessingToken::SAMPLE_ACCURATE, 1024);
scheduler->process_token(Vruta::ProcessingToken::FRAME_ACCURATE, 1);

Each call advances the corresponding clock and resumes all coroutines whose next_sample or next_frame has been reached. Different coroutines can exist in different temporal domains — an audio-rate coroutine ticking at sample resolution, a graphics-rate coroutine at frame resolution — and they never interfere because domain advancement is explicit and token-routed.

Composable Temporal Patterns

Beyond raw delays, Kriya provides higher-level awaiters that compose into complex temporal structures:

auto routine = [](Vruta::TaskScheduler& scheduler) -> Vruta::SoundRoutine {
    auto& promise = co_await Kriya::GetAudioPromise{};

    while (true) {
        if (promise.should_terminate) break;

        // Gate: suspend until a logic node outputs true
        co_await Kriya::Gate{scheduler, []() {
            schedule_another_clock();
        }, logic_node, true};

        // Dynamic timing from musical state
        float wait_time = calculate_musical_timing();
        co_await Kriya::SampleDelay{scheduler.seconds_to_samples(wait_time)};

        // Trigger: fire callback and synchronize
        co_await Kriya::Trigger{scheduler, true, []() {
            sync_frame_clock();
        }, sync_node};
    }
};

Gate, Trigger, SampleDelay, MultiRateDelay — each is a standalone awaiter. The coroutine body reads as a sequential description of temporal intent. The scheduler handles the mechanics of when to resume. State is stored in the coroutine frame itself and accessible externally via promise.get_state<T>() / promise.set_state().

Convenience API and Fluent Integration

For common patterns, convenience wrappers eliminate boilerplate:

MayaFlux::schedule_metro(2.0, []() { modulate_filter_cutoff(); }, "main_clock");

MayaFlux::schedule_pattern([](uint64_t beat) {
    return beat % 8 == 0;
}, []() { change_distribution(); }, 1.0, "pattern_trigger");

auto shape = vega.Polynomial({0.1, 0.5, 2.f});
shape >> Time(2.f);  // Creates coroutine, registers with TaskScheduler

Each of these constructs a SoundRoutine internally. schedule_metro builds a SampleDelay loop. schedule_pattern builds a conditional awaiter. The fluent >> operator on nodes creates NodeTimer coroutines that are automatically registered with the appropriate domain.

3 · Compile-Time Data Unification

Click to expand

Audio samples, pixel values, vertex positions, control voltages, at the machine level these are all just numbers. MayaFlux's type system treats them that way. Concepts like ArithmeticData and ComputeData constrain computation at compile time without encoding domain assumptions. DataVariant holds any numeric storage type. The same extractor, transformer, or analyzer works identically whether it's processing spectral data or a point cloud.

The Foundation: Universal Concepts in pch.h

MayaFlux defines concepts at the lowest level of the type hierarchy — in the precompiled header — so they’re available everywhere without include chains:

template <typename T>
concept ArithmeticData = std::is_integral_v<T> || std::is_floating_point_v<T>;

template <typename T>
concept ComplexData = requires {
    typename T::value_type;
    std::is_same_v<T, std::complex<float>> || std::is_same_v<T, std::complex<double>>;
};

template <typename T>
concept ContiguousContainer = requires(T t) {
    { t.data() } -> std::convertible_to<typename T::value_type*>;
    { t.size() } -> std::convertible_to<std::size_t>;
    typename T::value_type;
};

template <typename From, typename To>
concept SafeArithmeticConversion = ArithmeticData<From> && ArithmeticData<To>
    && (SafeIntegerConversion<From, To>
     || SafeDecimalConversion<From, To>
     || (IntegerData<From> && DecimalData<To>));

These are not audio concepts or graphics concepts. They describe data. Any function constrained by ArithmeticData works identically whether the data represents audio samples, pixel intensities, control voltages, or physics simulation parameters.

DataVariant: The Universal Container

DataVariant is a std::variant over every numeric storage type the framework supports:

using DataVariant = std::variant<
    std::vector<double>,
    std::vector<float>,
    std::vector<uint8_t>,
    std::vector<uint16_t>,
    std::vector<uint32_t>,
    std::vector<std::complex<float>>,
    std::vector<std::complex<double>>,
    std::vector<glm::vec2>,
    std::vector<glm::vec3>,
    std::vector<glm::vec4>,
    std::vector<glm::mat4>
>;

This is the type-erased boundary between domains. Audio data arrives as vector<double>, image data as vector<uint8_t> or vector<float>, vertex positions as vector<glm::vec3> — all held in the same container type. The framework doesn’t care about the origin domain; it cares about the data shape.

Semantic Access Without Templates on Containers

DataAccess and DataInsertion provide type-erased read/write over DataVariant with semantic dimension metadata:

DataAccess access(variant, dimensions, DataModality::AUDIO_1D);

auto audio_view = access.view<double>();      // span<double>
auto gpu_info   = access.gpu_buffer();        // (void*, byte_count, format_hint)
auto elems      = access.element_count();
auto comps      = access.component_count();   // 1 for scalar, 3 for vec3, etc.

Containers stay template-free. The template parameter lives on the view<T>() call — the user selects their access type, and DataAccess handles conversion if needed, caching the result for the lifetime of the accessor.

Extraction Traits: Compile-Time Data Routing

extraction_traits_d is a traits struct specialized per input type that tells the extraction system how to handle it at compile time:

template <> struct extraction_traits_d<Kakshya::DataVariant> {
    static constexpr bool is_multi_variant = false;
    static constexpr bool requires_container = false;
    static constexpr bool is_region_like = false;
    using result_type = std::span<double>;
};

template <> struct extraction_traits_d<Kakshya::Region> {
    static constexpr bool is_multi_variant = true;
    static constexpr bool requires_container = true;
    static constexpr bool is_region_like = true;
    using result_type = std::vector<std::span<double>>;
};

The ComputeData concept (in DataSpec.hpp) then unifies everything that can flow through the computation pipeline:

template <typename T>
concept ComputeData =
    std::same_as<T, Kakshya::DataVariant> ||
    std::same_as<T, std::vector<Kakshya::DataVariant>> ||
    std::same_as<T, std::shared_ptr<Kakshya::SignalSourceContainer>> ||
    std::same_as<T, Kakshya::Region> ||
    std::same_as<T, Kakshya::RegionGroup> ||
    std::same_as<T, std::vector<Kakshya::RegionSegment>> ||
    std::is_base_of_v<Eigen::MatrixBase<T>, T> ||
    VariantVector<T> ||
    std::constructible_from<Kakshya::DataVariant, T>;

Any ComputeOperation<InputType, OutputType> is constrained by ComputeData. Extractors, transformers, and analyzers are all templated on these types. The same UniversalExtractor<DataVariant, Eigen::MatrixXd> can extract a matrix from audio spectral data or from a point cloud — the operation doesn’t know or care.

Type-Safe Conversion with Auditable Safety

The try_convert<To>(from) system returns a CastResult<T> that carries the converted value, any error, and a precision_loss flag:

template <typename To, typename From>
CastResult<To> try_convert(const From& value)
{
    CastResult<To> result;
    if constexpr (SafeArithmeticConversion<From, To>) {
        result.value = static_cast<To>(value);
        result.precision_loss = (sizeof(From) > sizeof(To));
    } else if constexpr (ComplexData<From> && ArithmeticData<To>) {
        result.value = static_cast<To>(std::abs(value));
        result.precision_loss = (std::imag(value) != 0);
    }
    // ...
    return result;
}

No silent truncation. No unchecked casts. The conversion safety is expressed through concepts at compile time and diagnosed through CastResult at runtime.

4 · Multi-Domain Coexistence: A Working Example

Click to expand

Each subsystem {audio, graphics, input} carries its own ProcessingToken that routes through independent node graphs, buffer hierarchies, and scheduler clocks. These tokens compose into Domain values via bitfield operations, making domain membership decomposable and extensible. A single compose() function can declare audio synthesis, Vulkan rendering, and cross-domain coordination without shared locks or unified timing.

Processing Tokens: Independent Execution Contexts

Each subsystem (Nodes, Buffers, Coroutines) has its own ProcessingToken enum. These compose into unified Domain values via bitfield composition:

enum Domain : uint64_t {
    AUDIO = (uint64_t(Nodes::ProcessingToken::AUDIO_RATE) << 32)
          | (uint64_t(Buffers::ProcessingToken::AUDIO_BACKEND) << 16)
          | (uint64_t(Vruta::ProcessingToken::SAMPLE_ACCURATE)),

    GRAPHICS = (uint64_t(Nodes::ProcessingToken::VISUAL_RATE) << 32)
             | (uint64_t(Buffers::ProcessingToken::GRAPHICS_BACKEND) << 16)
             | (uint64_t(Vruta::ProcessingToken::FRAME_ACCURATE)),
};

Each domain is decomposable: you can extract the node token, buffer token, or scheduler token independently and compose custom domains from individual tokens.

Unified RingBuffer: Policy-Driven, Zero-Cost Dispatch

The Memory::RingBuffer is a single template parameterized by three orthogonal policies:

template <typename T, typename StoragePolicy,
          typename ConcurrencyPolicy = SingleThreadedPolicy,
          typename AccessPattern = QueueAccess>
class RingBuffer;

// Lock-free input queue: real-time thread → worker thread
using InputQueue = RingBuffer<InputValue,
    FixedStorage<InputValue, 4096>, LockFreePolicy, QueueAccess>;

// Audio delay line: single-threaded DSP
using AudioDelay = RingBuffer<double,
    DynamicStorage<double>, SingleThreadedPolicy, HistoryBufferAccess>;

// Real-time logging: audio thread → disk writer
using LogBuffer = RingBuffer<RealtimeEntry,
    FixedStorage<RealtimeEntry, 8192>, LockFreePolicy, QueueAccess>;

All dispatch is compile-time via if constexpr. LockFreePolicy uses alignas(64) atomic indices with acquire/release ordering. SingleThreadedPolicy uses plain size_t. HistoryBufferAccess reverses the push direction so operator[] with index 0 returns the newest sample — natural indexing for difference equations (y[n-1], y[n-2]).

Audio + Graphics in a Single Composition

void compose() {
    // Audio domain: modal synthesis driven by logic
    auto bell = vega.ModalNetwork(12, 220.0,
        ModalNetwork::Spectrum::INHARMONIC)[0] | Audio;

    auto osc = vega.Sine(0.2, 1.0f);
    auto logic = vega.Logic([](double input) {
        static double last = 0.0;
        bool crossed = (last < 0.0) && (input >= 0.0);
        last = input;
        return crossed;
    });
    osc >> logic;

    logic->on_change_to(true, [bell](auto& ctx) {
        bell->excite(get_uniform_random(0.5f, 0.9f));
        bell->set_fundamental(get_uniform_random(220.0f, 1000.0f));
    });

    // Graphics domain: Vulkan point collection
    auto window = MayaFlux::create_window({"Bell Visualization", 1280, 720});
    auto points = vega.PointCollectionNode(500) | Graphics;
    auto geom = vega.GeometryBuffer(points) | Graphics;
    geom->setup_rendering({.target_window = window});
    window->show();

    // Cross-domain coordination via metro coroutine
    MayaFlux::schedule_metro(0.016, [points]() {
        // Runs at ~60Hz, reads audio state, writes to graphics node
        float x = std::cos(angle) * radius;
        float y = std::sin(angle) * radius;
        points->add_point(Nodes::GpuSync::PointVertex{
            .position = glm::vec3(x, y, 0.0f),
            .color = glm::vec3(brightness, brightness * 0.8f, 1.0f),
            .size = 8.0f + radius * 4.0f
        });
    });
}

Audio processing runs at 48 kHz via AUDIO_BACKEND token. Graphics rendering runs at display refresh via GRAPHICS_BACKEND token. The metro coroutine bridges the two — its callback reads audio-domain state and writes to a graphics-domain node. The | Audio and | Graphics operators route nodes and buffers to their respective RootNode and RootBuffer hierarchies. No shared locks. Each domain processes its own graph independently; the coroutine provides temporal coordination.

5 · Thread Architecture: Where the Boundaries Actually Are

Click to expand

Three subsystems, three timing models, one coordination pattern. Audio is hardware-driven: RtAudio fires the callback, the sample counter advances. Graphics is self-driven: a dedicated thread ticks a FrameClock and paces its own frames. Input is event-driven: backend polling threads push to lock-free queues consumed by other subsystems. All three use the same SubsystemProcessingHandle interface -> same managers, different token-scoped views. Every thread boundary is crossed via CAS operations, atomic values, or coroutine-based coordination. No mutexes in any processing path.

Engine: Composition, Not Unification

Engine::Init constructs five independent managers — NodeGraphManager, BufferManager, TaskScheduler, WindowManager, InputManager — then hands them to a SubsystemManager that creates typed subsystems, each with its own thread model:

void Engine::Init(const GlobalStreamInfo& streamInfo,
                  const GlobalGraphicsConfig& graphics_config,
                  const GlobalInputConfig& input_config)
{
    m_scheduler = std::make_shared<Vruta::TaskScheduler>(streamInfo.sample_rate);
    m_buffer_manager = std::make_shared<Buffers::BufferManager>(
        streamInfo.output.channels, /* ... */ streamInfo.buffer_size);
    m_node_graph_manager = std::make_shared<Nodes::NodeGraphManager>(
        streamInfo.sample_rate, streamInfo.buffer_size);
    m_window_manager = std::make_shared<WindowManager>(graphics_config);
    m_input_manager = std::make_shared<InputManager>();

    m_subsystem_manager = std::make_shared<SubsystemManager>(
        m_node_graph_manager, m_buffer_manager, m_scheduler,
        m_window_manager, m_input_manager);

    m_subsystem_manager->create_audio_subsystem(streamInfo);
    m_subsystem_manager->create_graphics_subsystem(graphics_config);
    m_subsystem_manager->create_input_subsystem(input_config);
}

Each subsystem receives a SubsystemProcessingHandle — a scoped interface containing token-typed handles for buffers, nodes, and the scheduler. The handle constrains what a subsystem can touch: the audio subsystem’s handle routes through AUDIO_BACKEND / AUDIO_RATE / SAMPLE_ACCURATE tokens; the graphics subsystem’s handle routes through GRAPHICS_BACKEND / VISUAL_RATE / FRAME_ACCURATE. Same managers, different views.

AudioSubsystem: Hardware-Driven Clock

The audio callback is the only externally-driven timing source. RtAudio fires it at hardware interrupt rate. Inside, the processing follows a strict sequence:

int AudioSubsystem::process_output(double* output_buffer, unsigned int num_frames)
{
    m_callback_active.fetch_add(1, std::memory_order_acquire);

    // 1. Buffer-cycle tasks (metro callbacks, scheduled events)
    m_handle->tasks.process_buffer_cycle();

    // 2. Per-channel: process buffer chains, then collect network outputs
    for (uint32_t channel = 0; channel < num_channels; channel++) {
        m_handle->buffers.process_channel(channel, num_frames);
        all_network_outputs[channel] =
            m_handle->nodes.process_audio_networks(num_frames, channel);
        buffer_data[channel] = m_handle->buffers.read_channel_data(channel);
    }

    // 3. Per-sample: advance scheduler, sum node + buffer + network outputs
    for (size_t i = 0; i < num_frames; ++i) {
        m_handle->tasks.process(1);  // Advance coroutines by 1 sample

        for (size_t j = 0; j < num_channels; ++j) {
            double sample = m_handle->nodes.process_sample(j)
                          + buffer_data[j][i];

            for (const auto& net_buf : all_network_outputs[j]) {
                if (i < net_buf.size()) sample += net_buf[i];
            }

            output_span[i * num_channels + j] = std::clamp(sample, -1., 1.);
        }
    }

    // 4. Drain deferred operations (CAS pending slots)
    m_handle->nodes.cleanup_completed_routing();
    m_handle->buffers.cleanup_completed_routing();

    m_callback_active.fetch_sub(1, std::memory_order_release);
    return 0;
}

This is where the lock-free patterns from Section 1 pay off. Step 3 calls process_sample() on every node — which internally hits RootNode::preprocess() / postprocess() and its CAS-based pending operation drain. Step 1 calls process_buffer_cycle() which advances buffer-cycle-scoped coroutines. The scheduler’s process(1) in Step 3 advances sample-accurate coroutines by exactly one sample unit per iteration. No thread synchronization during the inner loop — all coordination was handled by the pending-op mechanism at cycle boundaries.

GraphicsSubsystem: Self-Driven Clock, Parallel Structure

The graphics subsystem spawns its own thread and drives its own timing — a fundamentally different model from AudioSubsystem, but the same handle structure:

void GraphicsSubsystem::start()
{
    m_running.store(true);
    m_frame_clock->reset();

    m_graphics_thread = std::thread([this]() {
        m_graphics_thread_id = std::this_thread::get_id();
        graphics_thread_loop();
    });
}

void GraphicsSubsystem::graphics_thread_loop()
{
    while (m_running.load(std::memory_order_acquire)) {
        if (m_paused.load(std::memory_order_acquire)) {
            std::this_thread::sleep_for(std::chrono::milliseconds(16));
            continue;
        }

        m_frame_clock->tick();       // Wall-clock driven, not hardware-driven

        process();                   // Same handle pattern as AudioSubsystem

        m_frame_clock->wait_for_next_frame();

        if (m_frame_clock->is_frame_late()) {
            uint64_t lag = m_frame_clock->get_frame_lag();
            if (lag > 2) {
                MF_RT_WARN(/* ... */ "Frame lag: {} frames behind (FPS: {:.1f})",
                    lag, m_frame_clock->get_measured_fps());
            }
        }
    }
}

The process() method is structurally parallel to the audio callback — pre-process hooks, task/node/buffer processing through the same handle interface, then Vulkan rendering and window management:

void GraphicsSubsystem::process()
{
    for (auto& [name, hook] : m_handle->pre_process_hooks) { hook(1); }

    m_handle->tasks.process(1);      // FRAME_ACCURATE coroutines
    m_handle->nodes.process(1);      // VISUAL_RATE nodes
    m_handle->buffers.process(1);    // GRAPHICS_BACKEND buffers

    register_windows_for_processing();
    m_backend->handle_window_resize();
    render_all_windows();            // Vulkan: acquire → record → submit → present
    m_handle->windows.process();
    cleanup_closed_windows();

    for (auto& [name, hook] : m_handle->post_process_hooks) { hook(1); }
}

The key architectural insight: audio timing is externally driven (hardware interrupt requests N frames), graphics timing is self-driven (FrameClock measures elapsed wall-clock time and ticks). Both subsystems process their respective RootNode and RootBuffer hierarchies through identical CAS-based patterns, but with different ProcessingToken values routing to different node/buffer graphs. The GraphicsSubsystem also registers a custom FRAME_ACCURATE processor with the scheduler so that frame-rate coroutines are resumed based on the self-driven FrameClock position rather than an external tick.

InputSubsystem: Event-Driven, Backend-Threaded

The input subsystem uses a third timing model — neither hardware-driven nor self-timed, but event-driven with backend-owned polling threads:

InputSubsystem::InputSubsystem(GlobalInputConfig& config)
    : m_config(config)
    , m_tokens {
        .Buffer = Buffers::ProcessingToken::INPUT_BACKEND,
        .Node = Nodes::ProcessingToken::EVENT_RATE,
        .Task = Vruta::ProcessingToken::EVENT_DRIVEN
    }
{}

void InputSubsystem::register_callbacks()
{
    // Input subsystem doesn't register timing callbacks like audio/graphics.
    // Backends push to InputManager's queue, which has its own thread.
}

Each backend (HID, MIDI, OSC, Serial) manages its own polling. HIDBackend runs a dedicated poll thread that reads raw reports and pushes InputValue events:

void HIDBackend::poll_thread_func()
{
    while (!m_stop_requested.load()) {
        {
            std::lock_guard lock(m_devices_mutex);
            for (auto& [id, state] : m_open_devices) {
                if (state->active.load() && state->handle) {
                    poll_device(id, *state);
                }
            }
        }
        std::this_thread::sleep_for(std::chrono::milliseconds(1));
    }
}

MIDIBackend uses RtMidi’s callback mechanism — rtmidi_callback fires on RtMidi’s internal thread, parses the MIDI message, and pushes an InputValue through the same path. Both backends converge on InputManager, which dispatches to registered InputNode instances. InputNode is a regular node in the processing graph — it reads from atomic target values written by the input thread and applies smoothing (linear, exponential, slew-limited) per sample during audio-rate processing:

double InputNode::apply_smoothing(double target, double current) const
{
    switch (m_config.smoothing) {
    case SmoothingMode::NONE:       return target;
    case SmoothingMode::LINEAR:     return current + (target - current) * m_config.smoothing_factor;
    case SmoothingMode::EXPONENTIAL: return m_config.smoothing_factor * target
                                          + (1.0 - m_config.smoothing_factor) * current;
    case SmoothingMode::SLEW: {
        double diff = target - current;
        return (std::abs(diff) <= m_config.slew_rate)
            ? target : current + (diff > 0 ? m_config.slew_rate : -m_config.slew_rate);
    }
    }
}

The boundary between input threads and processing threads is an atomic double — the input thread writes m_target_value, the audio thread reads it and applies smoothing. InputNode also supports callback-driven events (on_value_change, on_threshold_rising, on_button_press, while_in_range) that fire within the processing cycle.

Three Subsystems, Three Timing Models, One Pattern

AudioSubsystem       │ Hardware-driven (RtAudio callback)
                     │ Tokens: AUDIO_BACKEND, AUDIO_RATE, SAMPLE_ACCURATE
                     │ Clock: sample counter advanced by hardware request
                     │
GraphicsSubsystem    │ Self-driven (FrameClock + dedicated thread)
                     │ Tokens: GRAPHICS_BACKEND, VISUAL_RATE, FRAME_ACCURATE
                     │ Clock: wall-clock elapsed time, adaptive frame pacing
                     │
InputSubsystem       │ Event-driven (backend polling threads)
                     │ Tokens: INPUT_BACKEND, EVENT_RATE, EVENT_DRIVEN
                     │ Clock: none — events arrive asynchronously,
                     │        consumed by audio/graphics threads via atomics

Each subsystem constructs its SubsystemTokens at initialization and receives a SubsystemProcessingHandle scoped to those tokens. The handle provides the same tasks / nodes / buffers interface regardless of which subsystem holds it. The subsystem decides when and how to call process() — from a hardware callback, a self-timed loop, or not at all (input backends push to queues that other subsystems consume).

Every boundary between these threads is crossed via one of the mechanisms from Sections 1–4: CAS-claimed pending operations for graph mutation, lock-free ring buffers for event queues, atomic values for input→processing bridging, coroutines for temporal coordination, and processing tokens for domain routing. No mutexes in any processing path.

Architecture Summary

Layer	C++20/23 Feature	Role
Type System	Concepts, `constexpr`, variant	Domain-agnostic data unification
Concurrency	`atomic`, `compare_exchange`, `wait`/`notify`	Lock-free graph mutation during processing
Scheduling	Coroutines, `co_await`	Temporal coordination across timing domains
Data Structures	Templates, `if constexpr`, policy design	Zero-cost dispatch for storage/concurrency/access
Domain Composition	Bitfield enums, token routing	Independent execution contexts in one process

MayaFlux: Multi-Domain Real-Time Scheduling with C++20

Architectural Constraints of Heterogeneous Real-Time Systems

A Lock-Free, Coroutine-Centric Coordination Architecture

MayaFlux Architecture

1 · Lock-Free Coordination Across Thread Boundaries

The Pattern: CAS-Based Pending Operations

Atomic State Flags

Multi-Buffer Snapshot Coordination

Processing Cycle Fence

2 · C++20 Coroutines Weaving Temporal Intent

The Architecture: Vruta (Infrastructure) + Kriya (Patterns)

Sample-Accurate Delay

Clock Domains and Token-Based Routing

Composable Temporal Patterns

Convenience API and Fluent Integration

3 · Compile-Time Data Unification

The Foundation: Universal Concepts in pch.h

DataVariant: The Universal Container

Semantic Access Without Templates on Containers

Extraction Traits: Compile-Time Data Routing

Type-Safe Conversion with Auditable Safety

4 · Multi-Domain Coexistence: A Working Example

Processing Tokens: Independent Execution Contexts

Unified RingBuffer: Policy-Driven, Zero-Cost Dispatch

Audio + Graphics in a Single Composition

5 · Thread Architecture: Where the Boundaries Actually Are

Engine: Composition, Not Unification

AudioSubsystem: Hardware-Driven Clock

GraphicsSubsystem: Self-Driven Clock, Parallel Structure

InputSubsystem: Event-Driven, Backend-Threaded

Three Subsystems, Three Timing Models, One Pattern

Architecture Summary

Links
